Section 1
Overview
1.1
1.2
1.3
Scope
The AT91SAM9G10-EK evaluation kit is an effective platform for evaluating chip performance and
developing code for applications based on the AT91SAM9G10.
This guide is a description of the hardware included in the AT91SAM9G10-EK evaluation kit. Software
files are available embedded into the board’s memory upon delivery.
Deliverables
The AT91SAM9G10-EK package contains the following items:
an AT91SAM9G10-EK board
one A/B-type USB cable
one serial RS232 cable
one RJ45 crossed Ethernet cable
universal input AC/DC power supply with US and EU plug adapter
The AT91SAM9G10-EK Evaluation Board
The board is equipped with an AT91SAM9G10 (217-ball LFBGA package) together with the following:
64 Mbytes of SDRAM memory
256 Mbytes of NAND Flash memory
one Atmel ? serial DataFlash ?
one USB device port interface
two USB host port interfaces
one DBGU serial communication port
JTAG/ICE debug interface
one Ethernet 100-base TX with three status LEDs
one Atmel AT73C213 Audio DAC
one 3.5" 1/4 VGA TFT LCD Module with TouchScreen and backlight
one Power LED and two general-purpose LEDs
four user input pushbuttons
one wakeup input pushbutton
one reset pushbutton
one DataFlash SD/MMC card slot
AT91SAM9G10-EK Evaluation Board User Guide
1-1
6479A–ATARM–26-May-09
